3/16x5/8 BSW Hex Set Screw Zinc Grade 2
Internal Reference:
SET316B5/8ZP
3/16x5/8 BSW Hex Set Screw Zinc Grade 2
3/16x5/8 BSW Hex Set Screw Zinc Grade 2
- AS2451
- Hex Head
- Fully Threaded
- British Standard Whitworth
- Steel Zinc Plated CR+3
- Mild Steel Grade 2
Minimum | Maximum | ||
Threads per inch | 24 tpi | ||
D - Body diameter | 3/16" | ||
f - Across flats | 0.3250 | ||
h - Across corners | |
0.3720
| |
T - Head thickness | | 0.1280 | |
L - Overall length | 5/8" | |
Hex Set Screws is the term used for what is effectively a fully threaded hexagon head bolt which doesn't contain a shank (plain or unthreaded section). Although set screws can be used with a nut, typically they will be used in applications where they are threaded directly into something containing a matching pre-threaded hole such as a machinery component. The hex head set screw is designed to be tightened/removed with a suitably fitted wrench, spanner, socket or other hex driver.
