2-56x3/4 UNC Countersunk Socket Screw 304SS

https://firstchoiceindustrial.com.au/web/image/product.template/182847/image_1920?unique=d1f106b

$ 0.96 0.96 AUD $ 2.92

$ 2.65

Not Available For Sale

    This combination does not exist.

    Contact Us


    All prices are     GST inclusive

    Sign in or Create a user account to view pricing

    ​​Terms and Conditions


    Internal Reference: SSC2-56U3/4SS

    2-56x3/4 UNC Countersunk Socket Screw 304SS

    $ 0.96 0.96 AUD $ 2.92

    $ 2.65

    Not Available For Sale

      This combination does not exist.

      Flat head socket screw dimensions


      2-56x3/4 UNC Countersunk Socket Screw 304SS

      • ASME B18.3
      • Countersunk Hexagon Drive
      • United Coarse Thread
      • A2 70
      • 304 Stainless Steel
      		Minimum
      		Maximum
      Threads per inch
      		56 tpi

      D - Body diameter
      		​0.0822
      		0.0860
      A - Head diameter
      		​
      		0.1680
      		0.1970
      w - Hex key
      		 0.050


      G - Key depth​
      		 0.0380
      T - Head height​

      		0.0640
      L - Overall length3/4"


      c - Thread length
      		 5/8"
      ** All dimensions are in inches

      Countersunk socket screws, also known as flat head or simply flat socket head cap screws, are designed for use in applications where the head cannot protrude above the mating parts. They are set in 90° countersunk holes and the top of the head sits flush or slightly below the surface of the assembly.

      Dimensions are indicative only. Confirmation prior to ordering is advised if any of these dimensions are of critical importance to your application.
